Railway Track Monitoring

Railway Track Monitoring

One of the UK’s leading providers of railway track monitoring, SEP Rail Services offers both manual and automated monitoring systems that alert you immediately should any undue track movement occur.

What may appear to be insignificant changes in twist, cant or settlement can lead to disaster should they not be detected and resolved in time. Working in accordance with Network Rail Standards NR/L2/TRK/3100 and NR/L2/CIV/177, therefore, we operate throughout the country, delivering high-accuracy, cost-effective track monitoring data direct to your inbox.

Working with some of the UK’s most recognisable firms, we pride ourselves on the flexibility, responsiveness and accuracy of our track monitoring services. Thanks in part to these qualities, over 70% of our monitoring works is based upon repeat business.

Our clients

  • Primary Rail Contractors
  • Tier 2 Contractors
  • Tier 3 Contractors
  • Construction and Civil Engineering Companies Working Adjacent to Track
  • Other Survey Companies
Railway Track Monitoring
Railway Track Monitoring

Methodology

Whilst the automated or ‘remote’ systems we supply require considerably less human intervention (thus making them ideal for large or complex sites with poor access), the principles under which they operate remain the same. The following process describes our standard methodology for installing and maintaining a conventional, manual track monitoring regime…

  • A track monitoring plan (TMP) can be developed and submitted to the client for submission.
  • Once suitable targets have been selected, our technicians attach them to the web of the rail at three metre intervals.
  • Following the installation of the targets, a series of baseline readings are taken, against which all future readings – and potential movements – are compared.
  • During engineering works, the track is monitored on a regular basis with any undue readings (based on a series of pre-determined trigger levels) being reported and acted upon in accordance with the TMP.
  • Standard practice then demands that monitoring continues following completion of the work for a specified period, even if no movement has previously been recorded.
  • Once the final round of measurements has been taken, the targets are removed from the track.

Get in touch

Do you have a project that requires railway track monitoring? For more information on our monitoring services or to request a quote, please get in touch. A member of our team will be happy to help.
