Using the very latest technology, our measured building survey teams deliver accurate, intuitive plans and models of your structures, all in accordance with Network Rail standards.

In the context of the rail sector, a measured building survey could best be described as a dimensional survey of the internal and/or external areas of a building or civils structure. Such structures could range from station or depot buildings to bridges or tunnels. The end result can range from floor plans to fully-rendered, three dimensional Revit models.

Measured building survey deliverables

  • Floor plans
  • Roof plans
  • Sections
  • Elevations
  • Registered point clouds
  • Three dimensional BIM models
Measured Building Surveys
Measured Building Surveys

Depending upon the project specification, a wide variety of structural and architectural elements can be included within a measured building survey. These can range from simple walls, window and door openings to fenestration, masonry details, light fittings and more. Regardless of the elements captured, however, all drawings will include floor levels, heights and annotations as appropriate.

Key equipment

  • Trimble S9 0.5″ Robotic Station
  • Trimble TX8 Laser Scanner
  • Trimble SX10 3D Laser Scanning Total Station
  • Trimble TSC7 Data Logger
  • Handheld, Bluetooth-Enabled Laser Measuring Equipment
  • Touchscreen Field Computers Installed with MBS Software

Get in touch

To learn more about measured buildings surveys or to request a quote, please get in touch. A member of our team will be only too happy to help.
